Powerdynamo info needed on stock dynamo system

For projecting and manufacturing a new ignition/lighting unit, that will replace a DC dynamo, we need to know the following: (You will find additional information via the links in the text below)
What kind of motorcycle?	make year of manufacture engine number 2- or 4-stroke, number of cylinders
It's important to know, what you need:	ignition and light in a standard DC system (because of installed flashers and/or battery) ignition and light, where an AC system would be more adequate because of the smaller regulator ignition only lights only
To better understand what has to be done and to make you a detailed offer we will need a few photos:	close-up view of the engine from both sides close-up view of the original ignition/generator close-up view of engine area without the original unit, so that we can see the fixing points of the system
Are there any data for the original lighting/ignition system?	inscriptions on the rotor diameter and height of the rotor Are there some references in the user's manual? If you press the kickstarter - in what direction rotates the flywheel (clockwise oder counter-clockwise)?
A few points tend to be easily forgotten and than cause trouble. So we need to know	Does the oil seal rise above the bottom level of the system's stator plate? What are the dimensions of the rotor fastening screw? Is there an additional weight attatched to the rotor? How is the space situation between flywheel and engine cover
Once we have got all this information (maybe after a few additional questions)	we will make you a detailed offer If you accept this offer, we will need your original generator/ignition system to take dimensions (We will not temper with it in any way, you get it back as it was)
Back to "What to do for a new system"
